Product Description

Discover the I-CAR Shunting Procedure PDF, a vital resource for squeeze-type resistance spot welding (STRSW). Learn about the necessity of shunting current flow for successful spot welds, especially when dealing with non-conductive coatings like E-Coat. Dent Fix Shunting Pliers (Dent Fix DF-SP360) are essential for preserving E-Coat on mating surfaces during STRSW, ensuring efficient weld completion. With Dent Fix DF-SP360, coating removal, positioning the shunting clamp, and spot welding become effortless tasks, enabling rapid completion of projects. Ensure optimal performance with a 90-day warranty and a max amperage of 145 amps, making it suitable for various applications. Download the flyer now and equip yourself with top-quality tools from Dent Fix Equipment and Spitznagel Specialty Tools, trusted providers of innovative equipment since 1979. With Dent Fix, you’ll experience enhanced efficiency, reduced errors, and ultimately, cost savings on each project.

Description:

Dent Fix DF-SP360 removes coating from outside surfaces, positions the shunting clamp at the spot weld site, and makes the spot weld at the adjacent site. The current chooses the path of least resistance when confronting non-conductive E-Coat, facilitated by shunting pliers. The E-coat at the mating surface burns away quickly.

In squeeze-type resistance spot welding (STRSW), additional measures may be necessary to shunt the current flow for a successful spot weld. Conductive coatings like zinc or weld-through primer increase resistance but still allow for successful welds. However, non-conductive coatings like E-Coat hinder spot weld completion. Dent Fix Shunting Pliers (Dent Fix DF-SP360) can preserve E-Coat on mating surfaces during STRSW.

The process with using Dent Fix DF-SP360 is rapid, and although most current flows between electrode tips, the current detour is brief yet necessary.

iCAR requires shunting of current in STRSW for the first weld when a non-conductive coating like E-coat or adhesive is present on mating flanges. For weld bonding, a dedicated shunting clamp should be used for optimal weld performance, helping save E-coat by removing less with shunting pliers.

Max amperage: 145 amps
Copper Wire: 4 Gauge

90 day warranty.

I-CAR Shunting Procedure PDF | I-CAR Online Article

CLICK IMAGE TO DOWNLOAD FLYER

WARNING:

Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Features:

Dent Fix Equipment and Spitznagel Specialty Tools have been proudly providing technicians with the highest quality innovative equipment since 1979. Every year, Dent Fix introduces many new products to our customers, enhancing their efficiency in completing tasks. Moreover, Dent Fix Equipment enables technicians to finish jobs faster, reducing the risk of errors and ultimately saving them money on each project. Furthermore, our equipment lightens your workload, alleviating the stress accumulated by the end of the day.

Quality tools are invaluable, functioning reliably when needed and aiding users in speeding through their day.

From drilling through Boron Steel to fixing Aluminum Panels, measuring Vehicle Dimensions to Punching Plug Holes, Popping Plastic Rivets, Removing Undercoating, and Paintless Dent Repair to Self-Piercing Riveters, Dent Fix offers the latest tools and equipment from around the world, ensuring technicians have access to the most advanced solutions available.
